Product Application
Kilsaran KPRO Street T60 is a rapid setting, high strength bedding mortar designed for the bedding of ironworks as part of the Department of Transport Part 4 HD 27/94, where mortars for bedding ironwork (such as manhole cover frames) during repairs should reach 20N/mm² within 2 hours. Kilsaran T60 is also ideal for use in the following applications;
• Bedding and raising street ironwork
• Manhole frames and gullies
• Bedding posts, railings and bollards
• Bedding of precast units
• Emergency bedding of stone setts, slabs and cobbles

Product Use
Suitable for use in temperatures between +5°C and +30°C. Ensure the area is free from any dust, dirt or grease, presoaked and having all ponded water removed prior to application. Kilsaran T60 should be mixed in a forced action mixer or by hand with 2.5-2.7 litres of clean potable water, until a stiff, zero slump and homogenous mix is achieved. Mix only enough material that can be placed and finished in 5-10 minutes. Once mixed, place the fresh material in the prepared area at a depth from 10mm-75mm. For applications of greater depths, the material can be bulked out with well graded 10mm aggregate. When bedding frames ensure to position and level as soon as possible after placing. Exposed areas should be
given a floated finish. Once initial set of the material has taken place the area can be back filled.

Benefits
This product offers many advantages over conventional sitemixed or ready-mixed rendering mortars:
• Rapid Setting – Initial set in 15 minutes
• Shrinkage compensated
• Light foot traffic in just 1 hour
• High early and ultimate strength
• Long term durability
• Convenient and user-friendly
• Eliminates wastage
• Minimum traffic disruption

Technical Data
Kilsaran T60 is produced in an ISO 9001 quality-controlled environment.
